For corrugated roofing: roof tiles, profiled sheet metal and other roofing materials with a profile height of up to 45 mm.
Suitable for roofs with pitches from 15° to 90°
Version with aluminum-plastic apron
Double flashing for horizontal combinations
Double horizontal combination flashing EZV-A _X21 for corrugated roofing
The EZV‑A _X21 double flashing is designed for profiled roofing, where two roof windows installed side by side should form an aesthetic, perfectly aligned line. It is intended for roofing such as roof tiles, metal tiles, trapezoidal sheets and other materials with a profile height of up to 45 mm. It allows quick installation of horizontal combinations with a 10 cm spacing, ensuring a clean, cohesive and modern appearance of the roof surface. Its construction facilitates work on profiled roofing, providing secure window fitting and long‑lasting tightness. The set can be expanded with additional windows by using the EZV‑A _X02 central modules, enabling the creation of larger, visually impressive glazing arrangements. The flashing is available in three colours — anthracite (RAL 7016), grey‑brown (RAL 7022) and black (RAL 9005) — making it easy to match with the roof and FAKRO windows.
Assistance with installation
The installation of the EZV‑A _X21 double flashing makes it easy to create horizontal combinations on roofs covered with profiled roofing materials such as roof tiles or metal sheets. The precisely fitted top, bottom and side elements form a stable, watertight connection between the two windows, without the need for additional sheet‑metal work. The aluminium‑polymer apron adapts to the roofing profile, ensuring secure adhesion and effective protection against water and snow. The EZV‑A _X21 flashing guarantees an aesthetic finish and durable, aligned installation of the two windows in a single row.
Uniform roof aesthetics
FAKRO flashings in standard anthracite (RAL 7016) perfectly match the current colour trends in roofing. Black (RAL 9005) and grey-brown (RAL 7022) variants are also available upon request. The availability of three colour options allows the flashing to be matched to the window and roofing, creating a coherent and aesthetically pleasing look.
Corrugated roofing
The flashing designed for corrugated roofing ensures a tight and durable connection between the roof window and the roof surface made of tiles or profiled sheet metal. This universal solution can be used with all types of roofing with a profile of up to 45 mm. The system design effectively drains water and protects against snow and dust, while harmoniously blending in with the aesthetics of the roof, emphasising its consistent line.
A design refined in every detail
The EZV‑A _X21 double flashing is designed for horizontal combinations of two roof windows installed in profiled roofing such as roof tiles and metal sheets with a profile height of up to 45 mm. The set consists of upper, lower and side elements, a central gutter and cladding profiles for the sides of the window frame. These components ensure a watertight connection between the windows and the roof surface. The bottom element with a flexible aluminium‑polymer apron adapts to the roofing profile, providing durable insulation. The flashing construction allows the windows to be installed with the standard 100 mm spacing and ensures an aesthetic, repeatable finish of the combination. The set includes mounting components and an installation guide to simplify the assembly process.
Nasze produkty wyróżniają się tym, co naprawdę ma znaczenie. Poznaj cechy, które czynią je niezawodnymi i wyjątkowymi w codziennym użytkowaniu.
Three installation depths
FAKRO flashings allow for window installation at depths N, V and J. They are designed for installation at height V (0) as standard. On special request, we can manufacture flashings adapted for installation at height N (+3 cm) or J (–3 cm), ensuring a perfect fit to the roof surface.
High-quality materials
FAKRO flashings are manufactured from coated aluminium sheet with high resistance to weather conditions. This ensures long-term durability, effective protection against rain, snow and wind, and a perfect fit for roof windows.
