L-shaped combination windows

BXP P50 APXX

Where to buy
Size:

Energy-efficient glazing unit P50 (Uw =0.8 W/m²K)

Very good sound insulation Rw=40dB

Easy-to-clean coating

Installed under a roof window

BXP P50 APXX
BXP P50 APXX - Descriptions[0]

L-shaped combination window BXP P50 APXX

The non-opening BXP P50 APXX L-shaped combination window is a solution for those who want to fully exploit the potential of the knee wall, increasing the amount of light and the field of view. Installed under a roof window, it creates visually consistent glazing and emphasises the modern character of the interior. The fixed design improves safety – no option to open it eliminates the risk of accidental opening. The window can be combined with any type of roof window to create individual combinations tailored to the needs of the space.

BXP P50 APXX - Descriptions[1]

Energy and acoustic efficiency

The 44 mm thick P50 triple-glazed unit with thermoPro technology provides effective thermal insulation year-round. The heat transfer coefficient rated at 0.8 W/m²K translates into lower energy consumption and lower bills. The frame construction with a warm TGI spacer and a tight sealing system reduce heat loss and increase acoustic comfort. An insulation rating of Rw = 40 dB protects against noise and promotes peace and quiet inside.

BXP P50 APXX - Descriptions[2]

Aesthetics and durability for years to come

The anthracite cladding of the L-shaped combination window (RAL 7016) perfectly matches FAKRO roof windows, creating a consistent and elegant design – both from the outside and inside of the room. The uniform colour scheme and matching profiles ensure the visual harmony of the entire set. The interior gains a unique character thanks to natural pine wood, vacuum-impregnated and coated with a clear acrylic varnish, which emphasises the grain and introduces warmth and timeless elegance to the space.

See details of this product

Glazing unit P50

The triple-glazed unit with a thickness of 44 mm has been designed for high thermal and acoustic insulation. Toughened outer pane, laminated inner pane, argon and sound insulation film effectively increase comfort of use. The window achieves a heat transfer coefficient of Uw = 0.8 W/m²K. The design reduces external noise by 40 dB.

External cladding

The external cladding was designed in cooperation with the Institute of Industrial Design. Its modern, minimalist form emphasises the aesthetics of the window and harmonises with the roof line. The anthracite colour (RAL 7016) fits perfectly with current architectural trends. The colour consistency of the cladding, accessories and flashings creates a harmonious, elegant set that is resistant to weather conditions.

Internal finish

Carefully selected pinewood, vacuum impregnated and coated with a clear acrylic varnish, emphasises the natural character of the wood. This makes your interior cosy, warm and elegant. The finish is durable and resistant to everyday use, maintaining its aesthetic appearance for many years.

Glass

The P50 glazing unit ensures durability, safety and high comfort of use. The toughened outer glass is damage-resistant and comes with a lifetime hail warranty. The internal P2A class laminated glass increases safety by reducing the risk of injury in the event of breakage and makes it more difficult to force the window open during a break-in attempt. An additional acoustic film improves sound insulation, and the easy-to-clean coating makes cleaning the outer glass easier.

Get inspired by FAKRO

Looking for ideas? Explore our gallery to see how our products work in real spaces.

Dom o zerowym bilansie energetycznym na przedmieściach Wirginii

See inspiration

Characteristic features

Our products stand out for what truly matters. Discover the features that make them reliable and exceptional in everyday use.

thermoPro technology

The thermoPro technology provides effective thermal insulation, minimising heat loss in winter and protecting against overheating in summer. This solution guarantees year-round thermal comfort and noticeable energy savings.

topSafe system

The topSafe system enhances security thanks to reinforced window construction and resistance to break-in attempts or accidental opening. Your family gains peace of mind and complete home protection.

Environmentally conscious solution

The window is manufactured from FSC-certified wood and coated with water-based varnishes. Choosing this solution supports environmental protection and the idea of sustainable construction.

Easy-to-clean coating

The easy-to-clean coating keeps the outer pane clean for longer. Dirt such as dust and pollen is broken down by sunlight and washed away by rain. This saves you time and means you don't have to clean your windows as often.

Soundproofing

A triple-glazed unit with acoustic film and laminated glass effectively decreases noise by 40 dB. This improves acoustic comfort inside rooms by reducing street noise, neighbours' conversations and the sounds of everyday activities, among other things.

Design

The modern design of the cladding, developed in cooperation with the Institute of Industrial Design, emphasises the minimalist aesthetics of the window. Three colours – anthracite (RAL 7016), black (RAL 9005) and grey-brown (RAL 7022) – allow for a consistent match with the roof and accessories.

Specification BXP P50 APXX

All parameters refer to the selected size (78x60) using original assembly products
Dimensions
Nominal size (W x H)
78x60 cm
Clear opening width of the frame
688 mm
Clear opening height of the frame
458 mm
Clear sash opening width
591 mm
Clear sash opening height
378 mm
Clear reveal width
725 mm
Clear reveal height
496 mm
Material and appearance
Window construction type
L-shaped
Window colour
Natural wood pine
Window cladding colour
Anthracite RAL 7016
Window material
Vacuum impregnated pinewood
Cladding material
Aluminium
Varnish colour
naturalny
Varnish type
Acrylic
Number of varnish coats
2
Opening and control
Opening method
Non-opening
Control system
Non-opening
Solar power supply
No
Thermal insulation
Number of sealing gaskets
1 szt.
thermoPro
thermoPRO
Thermal transmittance coefficient Uw
0.8 W/m2K
Air permeability class
Class 4
Safety
Security class
topSafe
Resistance to wind load
Class C3
Watertightness
9A
Acoustic insulation
Sound reduction index Rw
40 dB
Sound reduction index Ra1
39 dB
Sound reduction index Ra2
35 dB
Equipment and accessories
Number of handles
1 szt.
Ventilator
Not applicable
Transport information
Product weight
26 kg
Package width
0.668 m
Package length
0.807 m
Package height
0.138 m
Packaging type
Tied with transportation belts
