Energy-efficient glazing unit P50 (Uw =0.8 W/m²K)
Very good sound insulation Rw=40dB
Installed under a roof window
![BVW P50 AWMX - Descriptions[0]](/_next/image?url=https%3A%2F%2Fcdn-pim.gofakro.com%2F%2FStrony%252520WWW%2FOkna%252520dachowe%2FOkna%252520kolankowe%2FBVW%252520P50%252520AWMX_AUY%2Fbvw-p50-awmx-02.webp&w=1920&q=75)
L-shaped combination window BVW P50 AWMX
The BVW P50 AWMX tilt L-shaped combination window is a functional solution installed in a knee wall. It perfectly matches the roof window, creating a coherent and elegant glazed surface. It provides maximum room illumination and allows the sash to be tilted by approximately 11 cm. This allows more natural light into the interior and provides effective ventilation. Air flow control increases everyday comfort and helps maintain a pleasant climate in the attic.
![BVW P50 AWMX - Descriptions[1]](/_next/image?url=https%3A%2F%2Fcdn-pim.gofakro.com%2F%2FStrony%252520WWW%2FOkna%252520dachowe%2FOkna%252520kolankowe%2FBVW%252520P50%252520AWMX_AUY%2Fbvw-p50-awmx-03.webp&w=1920&q=75)
Energy and acoustic efficiency
The 44 mm thick P50 triple-glazed unit with thermoPro technology provides effective thermal insulation year-round. The heat transfer coefficient rated at 0.8 W/m²K translates into lower energy consumption and lower bills. The frame construction with a warm TGI spacer and a tight sealing system reduce heat loss and increase acoustic comfort. An insulation rating of Rw = 40 dB protects against noise and promotes peace and quiet inside.
The triple-glazed unit with a thickness of 44 mm has been designed for high thermal and acoustic insulation. Toughened outer pane, laminated inner pane, argon and sound insulation film effectively increase comfort of use. The window achieves a heat transfer coefficient of Uw = 0.8 W/m²K. The design reduces external noise by 40 dB.
Characteristic features of L-shaped combination windows
Nasze produkty wyróżniają się tym, co naprawdę ma znaczenie. Poznaj cechy, które czynią je niezawodnymi i wyjątkowymi w codziennym użytkowaniu.
thermoPro technology
The thermoPro technology provides effective thermal insulation, minimising heat loss in winter and protecting against overheating in summer. This solution guarantees year-round thermal comfort and noticeable energy savings.
topSafe system
The topSafe system enhances security thanks to reinforced window construction and resistance to break-in attempts or accidental opening. Your family gains peace of mind and complete home protection.
Environmentally conscious solution
The window is manufactured from FSC-certified wood and coated with water-based varnishes. Choosing this solution supports environmental protection and the idea of sustainable construction.
Easy-to-clean coating
The easy-to-clean coating keeps the outer pane clean for longer. Dirt such as dust and pollen is broken down by sunlight and washed away by rain. This saves you time and means you don't have to clean your windows as often.
Soundproofing
A triple-glazed unit with acoustic film and laminated glass effectively decreases noise by 40 dB. This improves acoustic comfort inside rooms by reducing street noise, neighbours' conversations and the sounds of everyday activities, among other things.
Design
The modern design of the cladding, developed in cooperation with the Institute of Industrial Design, emphasises the minimalist aesthetics of the window. Three colours – anthracite (RAL 7016), black (RAL 9005) and grey-brown (RAL 7022) – allow for a consistent match with the roof and accessories.
