Prefabricated dormer

EDD-W

See where to buy this product
Size:

Two opening lower windows for ventilation

Aesthetic finish with sheet metal in the upper part

Easy installation

EDD-W
EDD-W - Descriptions[0]

Prefabricated dormer EDD-E

The prefabricated dormer  installed in the roof completely transforms the attic space, introducing more light and space. The use of four roof windows – two in the lower row and two in the upper row – makes the interior brighter, more comfortable and functional. The structure increases the functional area of the room, while emphasising the modern aesthetics of the building. As standard, the dormer is adapted for windows measuring 78x118 cm, with options available for 94x118 cm or 114x118 cm.

EDD-W - Descriptions[1]

Durable structure and easy installation

No crane is required for installation process, which allows for efficient installation even by one person. The EDD-E design is suitable for roofs with pitches from 35° to 70° and is fully compatible with FAKRO accessories, both external and internal, allowing for personalisation of the appearance and functionality of the attic. The entire structure is finished in an elegant RAL 7016 colour, which blends seamlessly with most roofing materials and contemporary façades.

Characteristic features of prefabricated dormers

Our products stand out where it really counts. Discover the features that make them reliable and built to last.

More natural light

Large glazing brightens up the attic and improves everyday comfort. The interiors become visually larger and more pleasant.

Increasing functional space

The extended structure creates additional space for free movement. This increases the functionality of the attic and facilitates its arrangement.

Aesthetic finish of the roof surface

The modern form of the dormer emphasises the building's appearance. Carefully refined details create an elegant complement to the roof.

EDD-W specification

All parameters apply to the selected size (78x118) when used with original installation accessories.
Type
Thermo
High profile up to 90 mm or 120 mm (H)
Dimensions
78x118 cm
Material and appearance
Lead apron
Equipment and accessories
Standard upper element, Standard lead apron, Standard middle element, Standard right side, Standard left side, Standard middle gutter, Frame side covering profiles_standard
Water drainage gutter, Roof rails, Insulation wedges, Installation set, Hooks, Insulation kit XDP, Fitting instructions, Insulation foam
Installation
30 °
70 °
Transport information
126.25 kg
1.357 m
2.629 m
0.774 m

For professionals

Logistics information

80AH06
78x118 cm
78x118 cm
