Underlays

EUROTOP ACTIV V 110

See where to buy this product
Size:

Effective vapour barrier with permeability Sd 0.5 - 3.5 m and basis weight 110 g/m²

Resistant in a wide temperature range (from -40°C to +120°C)

Resistant to weather conditions for up to three months

Guaranteed fire safety in class E*

EUROTOP ACTIV V 110
EUROTOP ACTIV V 110 - Descriptions[0]

EUROTOP ACTIV V 110

Ensure the durability and safety of your insulation with a vapour barrier membrane featuring a basis weight of 110 g/m². Designed for effective protection against moisture, it provides Sd permeability in the range of 0.5–3.5 m, effectively limiting water vapour penetration into the insulation layers. Its exceptional resistance to temperatures from -40°C to +120°C makes the membrane ideal for all conditions, from frosty winters to scorching summers. In addition, its durability allows it to be exposed to atmospheric factors for up to 3 months without losing its properties. The membrane features a flammability rating of class E. Its use is particularly recommended in combination with air-tight flashings and insulation kits, which form a coherent roof window protection system.

EUROTOP ACTIV V 110 specification

All parameters apply to the selected size (150,0 CM) when used with original installation accessories.
Type
Membrane type
Air tight
Foil type
ACTIVE
Dimensions
Roll width
150 cm
Roll length
50 mb
Basis weight
Grammage
110 g/m2
Material and appearance
Material
PP
Colour
White
Number of layers
3
Durability
Watertightness class
W1
Longitudinal tear strength
220 N/5 cm
Transverse tear strength
140 N/5 cm
UV resistance
3 miesiąc
Thermal insulation
Water vapour resistance (Sd value)
2 m
Fire resistance
Reaction to fire class
Basic flashing
Installation
Installation location
Roofing inside
Service temperature from
-40 °C
Service temperature to
120 °C
Transport information
Product weight
10.3 kg
Package width
0.18 m
Package length
1.52 m
Package height
0.18 m

For professionals

Logistics information

Item number
80AB07
Number of products per pallet
36 szt.
